Baumalight LXR524G Log Grapple
LXR524G Log Grapple – For Excavator
The Baumalight LXR524G is an excavator-mounted log grapple built to bring precision and efficiency to your forestry, land clearing, or debris handling work. Compact yet powerful, this attachment is engineered for operators who need more control in tight spaces without any dangling and the jaws and parts of the frame are designed with AR400 steel which is light weight yet stronger then normal steel.
The LXR524G features full 360° rotation, granting you full maneuverability to pick, grab, and place with ease. With a minimum jaw opening of about 3.25″ and a maximum opening over 50.3″, it handles a wide variety of log sizes. The reinforced build ensures long-term durability, while the design supports easy attachment, dependable handling, and efficient hydraulic performance.
Whether you're a contractor, landowner, or forestry professional, the LXR524G delivers high grip strength, consistent torque, and a size-optimized frame that makes it ideal for jobs where precision and power matter equally.
There are currently no customer photos or video submitted for this Baumalight product.Please check out similar products to see if there are submitted media available for those . Visit our Factory Discount web page to learn how you could participate in our Media Discount Program with your Baumalight product.
| LXR524G | |
|---|---|
| Rotation | 360° |
| Excavator Weight Range | 3.5 - 5 ton |
| Oil flow | 8 - 30 GMP |
| Torque at 25MPA | 1350 Nm (996 lb-ft) |
| Clamp Force | - |
| PSI | 2,500 - 4,000 |
| Minimum Opening Diameter | 3.25" |
| Maximum Opening | 50.3" |
| Min/Max log holding size | n3.25" - 24" |
| Width | 20" |
| Total Height | 43.4" |
| Weight | 329.3 lbs |
